Custom Hot DIP Galvanized Steel Grating with 30mm 40mm 60mm Pitch Bearing Bars for Trench Drain and Ground Walkway

Custom Hot DIP Galvanized Steel Grating with 30mm 40mm 60mm Pitch Bearing Bars for Trench Drain and Ground Walkway
Custom Hot DIP Galvanized Steel Grating with 30mm 40mm 60mm Pitch Bearing Bars for Trench Drain and Ground Walkway
Custom Hot DIP Galvanized Steel Grating with 30mm 40mm 60mm Pitch Bearing Bars for Trench Drain and Ground Walkway Custom Hot DIP Galvanized Steel Grating with 30mm 40mm 60mm Pitch Bearing Bars for Trench Drain and Ground Walkway Custom Hot DIP Galvanized Steel Grating with 30mm 40mm 60mm Pitch Bearing Bars for Trench Drain and Ground Walkway Custom Hot DIP Galvanized Steel Grating with 30mm 40mm 60mm Pitch Bearing Bars for Trench Drain and Ground Walkway

큰 이미지 :  Custom Hot DIP Galvanized Steel Grating with 30mm 40mm 60mm Pitch Bearing Bars for Trench Drain and Ground Walkway

제품 상세 정보:
접촉

Custom Hot DIP Galvanized Steel Grating with 30mm 40mm 60mm Pitch Bearing Bars for Trench Drain and Ground Walkway

설명
강조하다:

30mm Pitch Bearing Bars Steel Grating

,

40mm Pitch Bearing Bars Platform Grating

,

60mm Pitch Bearing Bars Metal Grating

Custom Hot DIP Galvanized Trench Drain Steel Grating for Ground Walkway Platform
Surface Process of Grating
Hot Galvanizing
Hot galvanizing is performed after the end welding process. For bearing bars with thickness ≥5mm, the average zinc layer weight will be ≥610g/m². For thickness <5mm, the average zinc layer weight will be ≥460g/m². Quality and requirements conform to GB/T 13912 standards.
Lacquering
Additional protection layer applied through spraying, brushing, or soaking methods.
Service Life of Hot Galvanizing
With a zinc coating thickness of 100μm, the product's anticipated lifespan varies according to environmental conditions.
Anti-Acid and Alkali Corrosion Capacity
Effective in pH range of 6-12.5, forming a stable protective film on the zinc surface with excellent anti-corrosive properties.
Calculation of Weight and Area
  • Weight increases after welding and galvanizing: 12% for 30mm pitch, 14% for 40mm pitch, and 16% for 60mm pitch bearing bars
  • Custom-sized gratings are calculated based on actual area (including cutouts and taps)
  • Gratings made to customer drawings are calculated by total outside dimensions
  • Unusual size cutouts are not deducted from length and width measurements
Custom Hot DIP Galvanized Steel Grating with 30mm 40mm 60mm Pitch Bearing Bars for Trench Drain and Ground Walkway 0
Easy-understanding specification chart of steel bar gratings
Vertical Bar Spacing Horizontal Bar Spacing Specification of Supporting Flat Steel (Width × Thickness)
30 100 G203/30/100 | G253/30/100 | G323/30/100 | G403/30/100 | G205/30/100 | G255/30/100
50 G203/30/50 | G253/30/50 | G323/30/50 | G403/30/50 | G205/30/50 | G255/30/50
40 100 G203/40/100 | G253/40/100 | G323/40/100 | G403/40/100 | G205/40/100 | G255/40/100
50 G203/40/50 | G253/40/50 | G323/40/50 | G403/40/50 | G205/40/50 | G255/40/50
60 50 - | G253/60/50 | G253/60/50 | G403/60/50 | G205/60/50 | G255/60/50
Vertical Bar Spacing Horizontal Bar Spacing Specification of Supporting Flat Steel (Width × Thickness)
30 100 G325/30/100 | G405/30/100 | G455/30/100 | G505/30/100 | G555/30/100 | G605/30/100
50 G325/30/50 | G405/30/50 | G455/30/50 | G505/30/50 | G555/30/50 | G605/30/50
40 100 G325/40/100 | G405/40/100 | G455/40/100 | G505/40/100 | G555/40/100 | G605/40/100
50 G325/40/50 | G405/40/50 | G455/40/50 | G505/40/50 | G555/40/50 | G605/40/50
60 50 G325/60/50 | G405/60/50 | G455/60/50 | G505/60/50 | G555/60/50 | G605/60/50
Custom Hot DIP Galvanized Steel Grating with 30mm 40mm 60mm Pitch Bearing Bars for Trench Drain and Ground Walkway 1 Custom Hot DIP Galvanized Steel Grating with 30mm 40mm 60mm Pitch Bearing Bars for Trench Drain and Ground Walkway 2
